HD TOF PET/MR
uPMR® 790
Watch the Video
Next Generation. Now Realized.
Next Generation. Now Realized.
The uPMR 790 enables simultaneous PET/MRI imaging with high temporal and spatial resolution. Next generation PET and MRI technologies redefine routine clinical imaging of real-time anatomical and functional imaging, while redefining cutting edge research imaging.
With a 32 cm Time-of-Flight (TOF) digital PET technology, industry leading 2.8 mm NEMA resolution and high 16 cps/kBq sensitivity, the uPMR 790 delivers exceptional PET image quality that is built upon the uEXPLORER® technology.
Redefining Precision PET Imaging
Empowered by United Compressed Sensing (uCS® 2.0) for ultra fast acquisition, powerful 45 mT/m; 200 T/m/s gradient performance, and world class homogeneity, the uPMR 790 produces fast, high-resolution MR imaging that can be acquired in real-time with 16x acceleration.
Redefining Cutting Edge MRI
The uSync research platform facilitates new research opportunities, including simultaneous tracking of PET and MR tracers, simultaneous cardiac PET and MR, functional neurological PET/MR, and multi-parametric radiomics.
Redefining PET/MR Research
Best In-Class Uniform Magnet
Unmatched homogeneity (0.055 ppm @ 30 cm DSV (Typical)), means that you can reliably achieve skin-to-skin fat saturation, while the spacious 50 x 50 x 50 cm field-of-view allows for easy patient positioning.
Digital LYSOPET Detectors
The ultra-large 32 cm PET FOV and 480 ps timing resolution and high sensitivity shorten whole-body exam times while capturing more signal data.
United Compressed Sensing (uCS 2.0)
uCS 2.0 is a novel approach to Compressed Sensing (CS) which incorporates prior knowledge of Partial Fourier, Parallel Imaging, and CS as weightings to mitigate artifacts and allows for exceptional acquisition speed and image quality.
2.8 mm NEMA PET Resolution
The 2.8 mm NEMA PET spatial resolution enables the precise detection of subtle lesions, providing comprehensive imaging for staging, treatment planning, and response assessment.
HYPER Iterative Reconstruction (ROSEM)
HYPER Iterative automatically finds the optimal converged solution resulting in reconstructed images with higher quantitative accuracy and better signal-to-noise ratio.
With the long axial PET field-of-view and ultra fast MR acquisition of uCS 2.0 you can provide PET/MR scanning at speeds that have not been achieved previously.
Several technologies combine to optimize workflow and make PET/MR more accessible, such as EasyPlan automatic bed planning, EasyScan 1-click MR scanning, intelligent image quality control, and intelligent MR-based attenuation correction.
With the high sensitivity of the SiPM digital detectors less tracer can be used for all patients including pediatrics.
The uSync research platform enables new levels of PET/MR research with simultaneous encoding of MRI sequences, list-mode PET data, and physiological information into the same raw data stream, fulfilling space-time synchronization.
